SentryIQ -Ghost

"Architecture-Grade Perimeter Security."

The SentryIQ Ghost is a professional-grade security sensor that fuses high-fidelity magnetic vectors with structural vibration data to provide near-zero false alarm rates.

Pre-Order Now Technical Specs

Core Capabilities

Cross-domain sensor fusion

3D Trajectory learning

Warp-field tamper detection

Sticky assault logic

“It doesn't just sense movement; it understands your home. By merging magnetic precision with structural awareness, SentryIQ eliminates the 'noise' of everyday life to provide security that is silent, certain, and sovereign.”

01 // Sensor Fusion

Cross-Domain Validation

The SentryIQ does not treat its sensors as isolated triggers; it uses them to validate one another in real-time. If a subtle magnetic shift is detected, the system checks the accelerometer. If there is a lack of corroborating sensor activations, the alarm is 'vetoed' as likely door/window-rattle or wind.

Veto Escalation: If an intruder tries to use vibration (like a drill or heavy knocking) to mask a slow pry attempt, the fusion logic detects the pattern and automatically upgrades the status to ASSAULT.

02 // Adaptive Learning

Dynamic Baselines

The system learns a 3D Trajectory, calibrating for OPEN, ALMOST CLOSED, and FULLY CLOSED positions to create a mathematical 'tunnel' that the magnet must stay within.

Golden Profile Adaptation: After hours of silence, the firmware performs 'Glacial Adaptation,' nudging the learned Golden Profile to match seasonal temperature shifts or building settling.

03 // Industrial Grade

Advanced Detection

Anti-Tamper (WARP Detection) utilizes 3D vector math to detect 'field curvature' shifts. If an intruder places a strong external magnet near the sensor, the system detects the Warp violation and triggers an alarm.

Sticky Assault Alarms: High-severity events are 'sticky' and cannot be cleared by returning the door or window to a closed state. They require a specific physical sequence or remote hub ACK.

TECH DEEP DIVE: The Ghost Engine

While most sensors rely on a single point of failure, the SentryIQ - Ghost utilizes a sophisticated Sensor Fusion architecture. By cross-referencing high-fidelity magnetic vectors with real-time structural vibration data, the system can distinguish between the heavy tread of an intruder and the natural shifting of a house or a gust of wind.

Architectural Schematics // Ghost Engine V1.0

Adaptive Environmental Profiling

Our engine accounts for 'Seasonal Drift.' Whether it’s the expansion of door frames in a humid summer or the contraction during a -30°C winter night, the Ghost continuously updates its baseline to maintain peak sensitivity without false alarms.

Multi-Profile Trajectory Modeling

By analyzing the specific 'signature' of a breach, SentryIQ provides industrial-grade security that ignores environmental interference while remaining hyper-alert to true threats.

Architectural Blueprint

Technical Specifications

Dimensions

30mm x 10mm (cylindrical), plus 150mm Pigtail (2 Wire)

Mounting

Door/Window Frame (Recessed)

Sensing Engine

Tri-axial Magnetometer + Ultra-sensitive Accelerometer

Detection Range

Up to 3cm Magnetic/Vibration

Update Frequency

Up to 250Hz (Real-time vector analysis)

Connectivity

Wired, Encrypted SentryLANE™ Communication Link

Architecture

Secure Recessed Sensor, must be connected to SentryCORE Hub. New Installations Require Custom Milling for Recessed Mounting

Sovereignty Disclaimer

Like all Tantallon hardware, the SentryIQ - Ghost operates on a strictly local basis. We do not require account creation, cloud connectivity, or recurring subscription fees to access the full capabilities of your hardware. Your home, your data, your control.
